Ai2152
ADDRESS
NAME
BIT
CONTENTS
51
(1108h)
APKNEE_Y512
7:0
Y for APKNEE curve when X=512. Y= APKNEE_Y512 *2
Y for APKNEE curve when X=640. Y= APKNEE_Y640 *2
Y for APKNEE curve when X=768. Y= APKNEE_Y768 *2
Y for APKNEE curve when X=896. Y= APKNEE_Y896 *2
52
(1109h)
APKNEE_Y640
APKNEE_Y768
APKNEE_Y896
APKNEE_Y1024
7:0
7:0
7:0
7:0
53
(110Ah)
54
(110Bh)
55
(110Ch)
Y for APKNEE curve when X=1024. Y= APKNEE_Y1024 *2
AP_CORN[5:0]
Reserved
5:0
7:6
3:0
7:4
4:0
7:5
Aperture corn control ? Corn = AP_CORN * 2
56
(110Dh)
AP_GAIN_P[3:0]
AP_GAIN_N[3:0]
Y_GAIN[4:0]
Reserved
Global Aperture gain for positive AP ? Gain= (AP_GAIN_P/4)
Global Aperture gain for negative AP ? Gain= (AP_GAIN_N/4)
Y GAIN control ? Gain = (1+Y_GAIN/32)
57
(110Eh)
58
(110Fh)
59
(0082h)
GAM_Y0
GAM_Y32
GAM_Y64
GAM_Y96
GAM_Y128
GAM_Y160
GAM_Y192
GAM_Y224
GAM_Y256
GAM_Y320
GAM_Y384
GAM_Y448
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
Y when X=0. (BLC OFF)
Y when X=32. (BLC OFF)
Y when X=64. (BLC OFF)
Y when X=96. (BLC OFF)
Y when X=128. (BLC OFF)
Y when X=160. (BLC OFF)
Y when X=192. (BLC OFF)
Y when X=224. (BLC OFF)
Y when X=256. (BLC OFF)
Y when X=320. (BLC OFF)
Y when X=384. (BLC OFF)
Y when X=448. (BLC OFF)
5A
(0083h)
5B
(0084h)
5C
(0085h)
5D
(0086h)
5E
(0087h)
5F
(0088h)
60
(0089h)
61
(008Ah)
62
(008Bh)
63
(008Ch)
64
(008Dh)
13
A1PROS [ A1 PROS CO., LTD. ]
