Ai2152
ADDRESS
NAME
BIT
CONTENTS
9E
(1159h)
LY_SPRS_STAR
T
7:0
Color suppress start level for low luminance.
LY_SPRS_SLOP
E
4:0
7:5
7:0
Color suppress slope for low luminance.
9F
(115Ah)
Reserved
A0
(115Bh)
HY_SPRS_STAR
T
Color suppress start level for high luminance.
Color suppress slope for high luminance.
HY_SPRS_SLOP
E
4:0
7:5
5:0
7:6
3:0
A1
(115Ch)
Reserved
AP_SPRS_STAR
T
Color suppress start level for aperture.
Color suppress slope for aperture.
A2
(115Dh)
Reserved
AP_SPRS_
SLOPE
A3
(115Eh)
Reserved
U_SLICE
V_SLICE
7:4
3:0
7:4
Slice = U_SLICE * 2
Slice = V_SLICE * 2
A4
(115Fh)
Maximum Y for AWB report.
(Unit: 4 level for 8 bits image data)
Y_MAX[5:0]
Reserved
5:0
7:6
5:0
7:6
7:0
A5
(1161h)
Minimum Y for AWB report.
(Unit: 4 level for 8 bits image data)
Y_MIN[5:0]
Reserved
A6
(1162h)
A7
Maximum C for AWB report.
C_MAX[7:0]
(1163h)
(Unit: 16 level for 7 bits image data)
Note : C_MIN ≦( U2 + V2 ) < C_MAX
C_MAX[9:8]
Reserved
1:0
7:2
A8
(1164h)
Minimum C for AWB report.
(Unit: 4 level for 7 bits image data)
A9
(1165h)
C_MIN[7:0]
7:0
UV_plane region enable select for AWB report.
UV_plane[0] : 0: region 1 disable. 1: region 1 enable.
UV_plane[1] : 0: region 2 disable. 1: region 2 enable.
UV_plane[2] : 0: region 3 disable. 1: region 3 enable.
UV_plane[3] : 0: region 4 disable. 1: region 4 enable.
UV_plane[3:0]
Reserved
3:0
7:4
AA
(1166h)
