Ai2152
ADDRESS
NAME
BIT
CONTENTS
Vertical active stop line of each field. (Unit: 1 Line)
Note:
NTSC ? 103h.
PAL ? 135h.
26
(106Eh)
TV_V_STOP[7:0]
7:0
V_V_STOP[8]
Reserved
0
27
(106Fh)
7:1
CCD Select:
00: NTSC 510X492
01: PAL 500X582
10: NTSC 768X494
11: PAL 752X582
CCD_SEL[1:0]
Reserved
1:0
5:2
7:6
28
(1080h)
Test Image mode
00: Disable Test Image (normal mode)
01: Replace AFE image data to internal test Gray pattern.
10: White Image
TEST_IMG[1:0]
11: Black Image
H_INV
RG_INV
0
1
H inverse. (1:inverted)
RG inverse. (1:inverted)
29
(1081h)
AD_LH_RIS
2
Data Latch with ADCLK edge. (0:falling edge 1:rising edge)
Reserved
6:4
7
CCD_SEL
1: for A1PROs CCD
H1_DELAY[2:0]
Reserved
2:0
3
H1 delay adjustment. (0-14ns delay)
2A
(1082h)
H2_DELAY[2:0]
Reserved
6:4
7
H2 delay adjustment. (0-14ns delay)
RG_DELAY[3:0]
RG_WIDTH[2:0]
Reserved
3:0
6:4
7
RG delay adjustment. (0-22ns delay)
2B
(1083h)
RG pulse width adjustment. (Decreasing 0-14ns)
SHP_DELAY[3:0]
SHP_WIDTH[2:0]
Reserved
3:0
6:4
7
SHP delay adjustment. (0-22ns delay)
2C
(1084h)
SHP pulse width adjustment. (Decreasing 0-14ns)
SHD_DELAY[3:0]
ADCLK_DELAY[3:0]
3:0
7:4
SHD delay adjustment. (0-22ns delay)
ADCLK delay. (0-22ns delay)
2D
(1085h)
2E
(1086h)
OBCLP_H_START[7:0]
OBCLP_H_START[9:8]
7:0
1:0
Horizontal start for OBCLP. (Unit: 1 pixel)
2F
(1087h)
10
A1PROS [ A1 PROS CO., LTD. ]
