VGDS2-DIP Series DC-DC Converter
Rev. 06-2006
Description
Features
Designed to convert fixed volt-
ages into an isolated voltage, the
VGDS2-DIP series is well suited
for providing board-mount local
supplies in a wide range of appli-
cations, including mixed
·Isolated 2 W output
·Temperature range: -40°C~+85°C
·Unregulated
·High efficiency to 82%
·Small footprint
·DIP package style
analog/digital circuits, test &
measurement equip.,
·Industry standard pinout
·UL94-V0 package
process/machine controls, data-
com/telecom fields, etc...
·No heatsink required
·6K Vdc isolation
·No external component required
·Low cost
The semi-regulated output can be
followed by 3-terminal regulators
to provide output protection, in
addition to output regulation.
Model
Input Voltage
Output
Voltage
5 Vdc
Output Current
Package
Number
Nominal
5 Vdc
Range
Max.
200 ?m
111 ?m
84 ?m
67 ?m
200 ?m
111 ?m
84 ?m
67 ?m
Min.
10 ?m
6 ?m
5 ?m
4 ?m
10 ?m
6 ?m
5 ?m
4 ?m
Efficiency
78%
Style
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
VGDS2-S5-D5-DIP
VGDS2-S5-D9-DIP
VGDS2-S5-D12-DIP
VGDS2-S5-D15-DIP
VGDS2-S12-D5-DIP
VGDS2-S12-D9-DIP
VGDS2-S12-D12-DIP
VGDS2-S12-D15-DIP
4.5~5.5 Vdc
4.5~5.5 Vdc
4.5~5.5 Vdc
4.5~5.5 Vdc
10.8~13.2 Vdc
10.8~13.2 Vdc
10.8~13.2 Vdc
10.8~13.2 Vdc
5 Vdc
9 Vdc
79%
5 Vdc
12 Vdc
15 Vdc
5 Vdc
80%
5 Vdc
80%
12 Vdc
12 Vdc
12 Vdc
12 Vdc
79%
9 Vdc
80%
12 Vdc
15 Vdc
82%
82%
Output Specifications
Item
Test conditions
Min.
0.2
Typ.
Max.
2
Units
W
Output power
Line Regulation
Load Regulation
Load Regulation
Output voltage accuracy
Te?perature drift
Output ripple
For Vin change of 1%
1.2
15
%
10% to 100% full load (5V Output)
10% to 100% full load (12V Output)
See tolerance envelope graph
100% load
%
10
0.03
200
%/°C
?Vp-p
KHz
20 MHz Bandwidth
100
35
Switching frequency
Full load, no?inal input
Note:
1. mll specifications ?easured at Tm=25°C, hu?idity <75%, no?inal input voltage and rated output load unless
otherwise specified.
