Ai2152
ADDRESS
NAME
BIT
CONTENTS
153
(00B4h)
G2_ADR_1[7:0]
7:0
GPIO2 Mapping Address 1, If Address = 0x00 -> Disable
GPIO2 Mapping Start Bit 1 (0~7)
G2_ADR_1[8]
G2_STABIT_1[2:0]
Reserved
0
154
(00B5h)
3:1
7:4
155
(00B6h)
G2_ADR_2[7:0]
7:0
GPIO2 Mapping Address 2, If Address = 0x00 -> Disable
G2_ADR_2[8]
G2_STABIT_2[2:0]
G2_BITNUM_2[3:0]
0
156
(00B7h)
3:1
7:4
GPIO2 Mapping Start Bit 2 (0~7)
GPIO2 Mapping Bit Num 2 (1~8)
157
(00B8h)
G3_ADR_1[7:0]
7:0
GPIO3 Mapping Address 1, If Address = 0x00 -> Disable
GPIO3 Mapping Start Bit 1 (0~7)
G3_ADR_1[8]
G3_STABIT_1[2:0]
Reserved
0
158
(00B9h)
3:1
7:4
159
(00BAh)
G3_ADR_2[7:0]
7:0
GPIO3 Mapping Address 2, If Address = 0x00 -> Disable
G3_ADR_2[8]
0
15A
(00BBh)
G3_STABIT_2[2:0]
G3_BITNUM_2[3:0]
3:1
7:4
GPIO3 Mapping Start Bit 2 (0~7)
GPIO3 Mapping Bit Num 2 (1~8)
15B
(00BCh)
G4_ADR_1[7:0]
7:0
GPIO4 Mapping Address 1, If Address = 0x00 -> Disable
GPIO4 Mapping Start Bit 2 (0~7)
G4_ADR_1[8]
G4_STABIT_1[2:0]
Reserved
0
15C
(00BDh)
3:1
7:4
15D
(00BEh)
G4_ADR_2[7:0]
7:0
GPIO4 Mapping Address 2, If Address = 0x00 -> Disable
G4_ADR_2[8]
G4_STABIT_2[2:0]
G4_BITNUM_2[3:0]
0
15E
(00BFh)
3:1
7:4
GPIO4 Mapping Start Bit 1 (0~7)
GPIO4 Mapping Bit Num 2 (1~8)
15F
(00C0h)
G5_ADR_1[7:0]
7:0
GPIO5 Mapping Address 1, If Address = 0x00 -> Disable
GPIO5 Mapping Start Bit 1 (0~7)
G5_ADR_1[8]
G5_STABIT_1[2:0]
Reserved
0
160
(00C1h)
3:1
7:4
29
