Ai2152
ADDRESS
NAME
BIT
CONTENTS
F7
(0101h)
Y_MIN_CNT[15;8]
7:0
Minimum Y count
F8
(0102h)
PRINT_FLAG [7:0]
7:0
7:0
F9
(003Dh)
LL_STEP_SIZE [7:0]
Step size of line-lock comp
Maximum Line-Lock frequency
1/60 (1/50) – (LL_FREQ_MAX * 2048 Tsys_clk)
LL_FREQ_MAX [3:0]
LL_FREQ_MIN [3:0]
3:0
7:4
FA
(003Eh)
Minimum Line-Lock frequency
1/60 (1/50) + (LL_FREQ_MIN * 2048 Tsys_clk)
High Light suppression mode. (switch data at AE,Y)
0: Disable
1: AE switch on.
2: Y switch on.
3: AE, Y switch on.
(Active while MCRDIP = 1 or HLI_EN = ‘H’ )
HLS_MODE [1:0]
AWB_RANGE
1:0
4:2
FB
(003Fh)
000: 2500oK~9500oK
001: 3100oK~5100oK
010: 3100oK~6500oK
011: 2800oK~4700oK
100: 2500oK~15000oK
Reserved
Reserved
7:5
7:0
FC~FF
100
(0040h)
C_M11_LT[7:0]
C_M12_LT[7:0]
C_M13_LT[7:0]
C_M21_LT[7:0]
C_M22_LT[7:0]
C_M23_LT[7:0]
C_M31_LT[7:0]
C_M32_LT[7:0]
C_M33_LT[7:0]
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
C_M11 of color matrix at low color temperature.
C_M12 of color matrix at low color temperature.
C_M13 of color matrix at low color temperature.
C_M21 of color matrix at low color temperature.
C_M22 of color matrix at low color temperature.
C_M23 of color matrix at low color temperature.
C_M31 of color matrix at low color temperature.
C_M32 of color matrix at low color temperature.
C_M33 of color matrix at low color temperature.
101
(0041h)
102
(0042h)
103
(0043h)
104
(0044h)
105
(0045h)
106
(0046h)
107
(0047h)
108
(0048h)
24
